Product overview Auto²Scan Color
The Auto²Scan Color is an advanced vehicle underbody inspection system that enables highly precise, real-time color imaging. Developed for target groups such as appraisers, automotive manufacturers, workshops, vehicle logistics companies, and security authorities, it offers an optimal solution for detailed inspections and quality control. This article presents the system's technical specifications and unique features to illustrate its performance and versatility.
System structure
The Auto²Scan Color consists of a high-resolution color camera, a powerful Raspberry Pi 5 for control and image processing, vehicle identification (e.g., license plate recognition or barcode scanner), and a robust drive-over structure. Image capture starts automatically as soon as a vehicle drives over the system, and the image appears in real time on a connected device (PC, laptop, tablet, or smartphone). Operation is via the auto2scan software, which runs on the Raspberry Pi 5¹ and is accessible through a web browser.
Main components
- Digital color GigE camera with 2K resolution (2046 pixels) and wide-angle lens
- Lighting with: 40 SMD LEDs (white) with focusing optics,
- Two sensors for start and stop detection.
- Available as a mobile version (up to 3.5 t) or a stationary version (up to 12.5 t).
¹ The Raspberry Pi 5 is a powerful single-board computer from the Raspberry Pi Foundation, released in October 2023. Featuring a 2.4 GHz quad-core Arm Cortex-A76 processor, up to 16 GB of RAM, and a VideoCore VII GPU, it offers a 2- to 3-fold performance increase over its predecessor. Equipped with PCIe 2.0, USB 3.0, dual-band Wi-Fi, Bluetooth 5.0, and dual 4Kp60 HDMI output, it is ideal for safety-critical applications.
Drive-over construction – system designs
Mobile drive-over structure
- Weight: approx. 730 kg
- Material: Robust construction for vehicles up to 3.5 t
- Installation: Flexible application, ideal for temporary or mobile locations
Stationary crossing structure
- Load class: B 125 according to DIN EN 124, for vehicles up to 12.5 t
- Weight: approx. 730 kg
- Installation: Flush with the floor, recessed into the roadway for permanent installations
How it works
The image capture starts automatically as soon as a vehicle drives over the system. The color camera records the vehicle's undercarriage as it moves across the system. The captured color image, along with the license plate number or VIN, is displayed in real time on a device (PC, laptop, tablet, or smartphone) connected to the Raspberry Pi 5 via Wi-Fi or LAN. The Auto²Scansoftware, installed on the Raspberry Pi 5, allows for control and image processing (currently only available to us, as it is not configurable via a GUI). After capture, the image can be downloaded as a JPG file via a web browser and used further.
Technological advantage for workshops, testing facilities and safety authorities
The Auto²Scan Color is specifically tailored to the needs of expert assessment centers, car manufacturers, workshops, vehicle logistics companies and security authorities:
- Precise color images: The 2K color camera delivers detailed images, ideal for inspections and documentation.
- Real-time capture: Automatic image capture at speeds up to 30 km/h for maximum efficiency.
- Ease of use: Intuitive operation via the Auto²Scan software; images can be saved as JPG files.
- Robust and flexible: Mobile and stationary versions for different application scenarios.
- Easy integration: Seamless integration into existing processes thanks to PoE and network options (WLAN/LAN).
Areas of application – Versatile use from testing to safety
Auto²Scan Color is specifically designed for the following target groups and areas of application:
- Testing centers and expert assessment centers: Detailed documentation for general inspections and vehicle valuations.
- Automotive industry: Quality control in production to ensure manufacturing standards.
- Workshops and service centers: Precise diagnoses of underbody damage or wear to improve customer satisfaction.
- Vehicle logistics: Traceable documentation of the vehicle's condition upon entry and exit.
- Security authorities: Inspection of vehicle undercarriages at border crossings, ports or at major events to identify contraband or hazards.
Application examples
These sample images from Auto²Scan Color demonstrate the high image quality and highlight the system's suitability for precise underbody analysis. Note : All images are copyrighted.
Conclusion
With the Auto²Scan Color , you get a technically sophisticated system that sets the highest standards in vehicle underbody inspection. The combination of high-resolution color images, robust construction, and ease of use makes it the perfect choice for your needs – whether in quality control, maintenance, or safety inspections. Contact us to learn more about how this system can optimize your processes.
Would you like a consultation or a live demo?
We would be happy to advise you personally.
Contact us for further information or a private demonstration.
