Product overview Auto²Scan Color
The Auto²Scan Color is an advanced vehicle underbody inspection system that enables highly precise, real-time color imaging. Developed for target groups such as appraisers, automotive manufacturers, workshops, vehicle logistics companies, and security authorities, it offers an optimal solution for detailed inspections and quality control. This article presents the system's technical specifications and unique features to illustrate its performance and versatility.
System structure
The Auto²Scan Color consists of a high-resolution color camera, a powerful Raspberry Pi 5 for control and image processing, vehicle identification (e.g., license plate recognition or barcode scanner), and a robust drive-over structure. Image capture starts automatically as soon as a vehicle drives over the system, and the image appears in real time on a connected device (PC, laptop, tablet, or smartphone). Operation is via the auto2scan software, which runs on the Raspberry Pi 5¹ and is accessible through a web browser.
Main components
- Digital color GigE camera with 2K resolution (2046 pixels) and wide-angle lens
- Lighting with: 40 SMD LEDs (white) with focusing optics,
- Two sensors for start and stop detection.
- Available as a mobile version (up to 3.5 t) or a stationary version (up to 12.5 t).
¹ The Raspberry Pi 5 is a powerful single-board computer from the Raspberry Pi Foundation, released in October 2023. Featuring a 2.4 GHz quad-core Arm Cortex-A76 processor, up to 16 GB of RAM, and a VideoCore VII GPU, it offers a 2- to 3-fold performance increase over its predecessor. Equipped with PCIe 2.0, USB 3.0, dual-band Wi-Fi, Bluetooth 5.0, and dual 4Kp60 HDMI output, it is ideal for safety-critical applications.
Drive-over construction – system designs
Mobile drive-over structure
- Weight: approx. 730 kg
- Material: Robust construction for vehicles up to 3.5 t
- Installation: Flexible application, ideal for temporary or mobile locations
Stationary crossing structure
- Load class: B 125 according to DIN EN 124, for vehicles up to 12.5 t
- Weight: approx. 730 kg
- Installation: Flush with the floor, recessed into the roadway for permanent installations
How it works
The image capture starts automatically as soon as a vehicle drives over the system. The color camera records the vehicle's undercarriage as it moves across the system. The captured color image, along with the license plate number or VIN, is displayed in real time on a device (PC, laptop, tablet, or smartphone) connected to the Raspberry Pi 5 via Wi-Fi or LAN. The Auto²Scansoftware, installed on the Raspberry Pi 5, allows for control and image processing (currently only available to us, as it is not configurable via a GUI). After capture, the image can be downloaded as a JPG file via a web browser and used further.
Technological advantage for workshops, testing facilities and safety authorities
The Auto²Scan Color is specifically tailored to the needs of expert assessment centers, car manufacturers, workshops, vehicle logistics companies and security authorities:
- Präzise Farbbilder: Die 2K-Farbkamera liefert detailreiche Aufnahmen, ideal für Inspektionen und Dokumentationen.
- Echtzeit-Erfassung: Automatische Bildaufnahme bei Geschwindigkeiten bis 30 km/h für maximale Effizienz.
- Benutzerfreundlichkeit: Intuitive Bedienung über die Auto²Scan-Software, Bilder können als JPG-Dateien gespeichert werden.
- Robust und flexibel: Mobile und stationäre Varianten für unterschiedliche Einsatzszenarien
- Easy integration: Seamless integration into existing processes thanks to PoE and network options (WLAN/LAN).
Areas of application – Versatile use from testing to safety
Auto²Scan Color is specifically designed for the following target groups and areas of application:
- Prüfstellen und Gutachterzentren: Detaillierte Dokumentation für Hauptuntersuchungen und Fahrzeugbewertungen.
- Automobilindustrie: Qualitätskontrolle in der Produktion, um Fertigungsstandards sicherzustellen.
- Werkstätten und Servicezentren: Präzise Diagnosen von Unterbodenschäden oder Verschleiß zur Verbesserung der Kundenzufriedenheit.
- Vehicle logistics: Traceable documentation of the vehicle's condition upon entry and exit.
- Sicherheitsbehörden: Kontrolle von Fahrzeugunterböden an Grenzübergängen, Häfen oder bei Großveranstaltungen zur Identifikation von Schmuggelware oder Gefahren.
Application examples
Diese Beispielaufnahmen von Auto²Scan Color demonstrieren die hohe Bildqualität und unterstreichen die Eignung des Systems für präzise Unterbodenanalysen. Hinweis: Alle Bilder sind urheberrechtlich geschützt.
Conclusion
Mit dem Auto²Scan Color erhalten Sie ein technisch ausgereiftes System, das höchste Standards in der Fahrzeugunterboden-Kontrolle setzt. Die Kombination aus hochauflösenden Farbbildern, robuster Bauweise und einfacher Handhabung macht es zur perfekten Wahl für Ihre Anforderungen – sei es in der Qualitätskontrolle, Wartung oder Sicherheitsüberprüfung. Kontaktieren Sie uns, um mehr darüber zu erfahren, wie dieses System Ihre Prozesse optimieren kann.
Would you like a consultation or a live demo?
Wir beraten Sie gerne persönlich.
Kontaktieren Sie uns für weitere Informationen oder eine individuelle Vorführung.
